Scale models for engineering studies can help evaluate seastead designs.

Basically if you scale dimensions down by 25 and speed down by 5 things will happen at the same relative fraction of hull speed. If wave heights and wave lengths are scaled by 25 then wave speeds are also down by 5. So things work out well. However, in the model everything is happening 5 times faster. So if you see something tip back and forth every 2 seconds in the model it would be every 10 seconds in the full sized version. A 10 knott wind in the model is like a 50 knott wind in full scale. The important relationship between 25 and 5 is that 5 is the square-root of 25. Works for other numbers with this important relationship too.


External links on scale modeling

 * Wikipedia Similitude (model)
 * Wikipedia Similitude of ship models
 * Wikipedia Ship model basin
 * Wikipedia Response amplitude operator
 * Wikipedia Port Revel Shiphandling Training Centre

Related

 * Wikipedia Ship motions
 * Wikipedia Seakeeping
 * Wikipedia Ship stability
 * Vince Cate Models

Computer modeling

 * Ultramarine on boat modeling
*blender
